The steel bar cage production equipment controlled by PLC ended the history of manual binding of steel cages. It's widely used in highway, high-speed railway, rail transit, power engineering, water conservancy projects and other projects. The equipment is mature, stable and easy to operate. Customers can choose the matching double gun automatic welding manipulator.





Model	LYGH-1500	LYGH-1800	LYGH-2000	LYGH-2200	LYGH-2500	LYGH-3000
Steel cage pile diameter	500~1500	500~1800	600~2000	600~2200	800~2500	800~3000
Equipment power	16KW	18KW	23KW	23KW	25KW	38KW
Occupied area(No side automatic welding)	28m×6m	28m×6m	28m×6.5m	28m×7m	28m×9m	28m×11m
Occupied area(Including side automatic welding)	28m×8.5m	28m×8.5m	28m×9m	28m×9.5m	28m×11.5m	28m×13.5m
Cage length	12m, Customizable
Diameter of main bar of steel cage	Φ16~50
Diameter of winding bar of steel cage	Φ5~16
Welding method of the winding bar	Welding robot or manual
Distance between two winding bars	≤300mm
Hydraulic pressure	≤16MPa
Gas pressure	≤0.8MPa, Automatic welding gas
Welding power	30KW, Double guns automatic welding
Number of operators	1-2 persons, Double guns automatic welding 2-4 persons, Manual welding
Production efficiency	8 sections/10h, Refer to the actual site environment





The working principle of steel cage welding machine:



According to the construction requirements, the main bar of the steel cage is fixed manually through the corresponding circular hole of the template of the fixed rotating disc to the corresponding hole of the moving rotating disc, and the end of the disc (winding) is welded on a main bar first, and then the winding bar is wound on the main bar by rotating the fixed rotating disc and moving rotating disc (the moving disc is rotated while moving), and welding is carried out at the same time. Thus forming the product steel cage, which is the working principle of the bored pile steel cage hobbing welding machine, that is, the "steel cage forming machine".



Advantages of steel cage welder:



1, PLC automatic control, touch screen adjustment, high degree of automation.



2, moving disk walking and carriage return are automatic walking, improve the degree of equipment automation.



3, stirrup does not need to lap, compared with manual work to save one percent of the material, reducing the construction cost.



4, mechanized production of steel cage, the main bar, winding bar spacing is uniform, high precision, stable processing quality.



5, the degree of automation of the equipment is high, the processing and molding speed is fast, under the same conditions, the mechanical production is 3-4 times the output of manual production. The processing cost is greatly reduced, the use of mechanical production, reducing more than 2/3 processing personnel.



6, the mold ring can be replaced, the production of different diameters of steel cage only need to replace the mold ring can be completed, easy to operat
